C3 USB camera
€1.00
| Camera interface: | USB-C 2.0 |
|---|---|
| Camera kind: | Boxed |
| Chroma: | RGB |
| Filter: | IRCUT |
| Image sensor: | IMX415 |
| Lens mount: | CS |
| Sensor size: | 1/2.8" |
| HS CODE: | 8525 89 |
| Shutter: | Rolling shutter |
| Frame rate: | 60 fps |
| Country Of Origin: | Lithuania |
| Resolution: | 8 MP |
| ECCN: | EAR99 |
Accessories
USB-C cable with lock screws offers a robust and reliable connection tailored for industrial and machine vision applications. Designed to mate USB Type-A at one end and USB-Type-C at the other, it features M2 lock screws with 15mm spacing to secure the connector firmly in place - ideal in environments subject to vibration or motion. The cable uses a durable outer PVC jacket, and measures approximately 4.2mm in diameter. Cable is dual shielded, 32 AWG (data), and 24 AWG (power), ensuring consistent power and data transmission and low voltage drop. This cable is purpose-built to complement the C2 and C3 camera series providing a secure, high-integrity link between the camera and host system. Whether in factory automation, inspection systems or embedded vision rigs, the lock-screw USB-C cable helps maintain connectivity and performance even under demanding conditions.
Aluminum adapter for low profile / short back focus M12 mount lenses. To be used with CS-mount type cameras.
Universal compact lens with manual focus, zoom and iris for CS cameras. Suitable for high pixel density sensors. Lens has thumb screws for all rings, and can be mounted in industrial environment.
Tripod and Arca-Swiss mount plate kit. This mount plate is designed to make camera more compact and add more mounting options.
Lenses
Universal compact lens with manual focus, zoom and iris for CS cameras. Suitable for high pixel density sensors. Lens has thumb screws for all rings, and can be mounted in industrial environment.
